Encvoy ID Overview — Single Sign-On (SSO) System#

Encvoy ID is a Single Sign-On (SSO) system for centralized user authentication and access management for enterprise applications.

The system provides secure centralized authentication with support for SSO, OAuth 2.0, OpenID Connect, and two-factor authentication.

Use Cases for Encvoy ID#

Encvoy ID is a system designed to organize centralized user login to corporate information resources using a single account.

Encvoy ID is aimed at companies that require:

  • Single sign-on window for internal and external services
  • Centralized access management for different categories of users (employees, contractors, clients)
  • Enhanced security with multi-factor authentication support
  • Strict control and audit of user actions
  • Secure integration of multiple applications with different authentication systems

Key Features of Encvoy ID#

1. Authentication and Login#

The system provides centralized authentication and supports multiple protocols and authentication methods.

Supported Protocols#

  • OpenID Connect (OIDC) — user authentication and identity data transfer
  • OAuth 2.0 — authorization and resource access management

Authentication Methods#

  • Basic methods: login and password, email
  • External Identity Providers: social networks, trusted corporate systems, and other services
  • Enhanced and passwordless methods: cryptographic authentication via mTLS (client certificates) and WebAuthn (biometrics, hardware keys), as well as TOTP/HOTP one-time passwords

Two-Factor Authentication (2FA / MFA)#

Encvoy ID supports multi-factor authentication (MFA), where access is granted only after successful identity verification using several independent factors (knowledge, possession, biometrics).

2. Application and User Management#

  • Application creation and configuration: web applications, native mobile applications
  • Widget customization: tailoring the external authentication widget to the company's brand
  • User management: registration, editing, blocking, password changes

3. Security and Audit#

  • Access rights differentiation
  • Detailed logging of all events and actions

4. Mini-widget#

A lightweight JavaScript component that provides quick access to authentication functions and user information. It is easily embedded into any websites and interfaces, providing transitions to the profile, organization dashboard, and applications.

Access Levels#

The system provides a flexible role-based access model:

Role Permissions Intended For
Manager Management of applications and login methods for their organization/unit Department heads, project managers
Administrator of application Management of specific applications and their users Developers, application administrators
Member Management of personal profile and permissions for personal data access Regular users, employees

Encvoy ID System Modules#

1. Profile#

The "Profile" module provides management of personal user data and access settings. It includes functions for editing personal information, privacy settings, managing application permissions, and viewing activity logs. The module also provides access to the public application catalog.

2. Organization Dashboard#

The "Organization Dashboard" module provides management of applications, authentication methods, and access policies within the organization. It includes organization parameter settings, login method configuration, organization application management, and user activity monitoring.

3. Application Dashboard (ADM)#

The "Application Dashboard" module is designed for the administration of individual applications. It contains functions for managing assigned applications and monitoring the activity of users who have access to these applications.

Concept and Operating Principles of Encvoy ID#

General Interaction Scheme#

General interaction scheme of Encvoy ID with corporate systems

Interaction Sequence:

  1. Access Request — the user accesses the information system (IS).
  2. Check in IS DB — the system checks for the user's existence.
  3. Redirect to Widget — the user is directed to Encvoy ID.
  4. Authentication — the user undergoes the login procedure.
  5. Check in Encvoy ID DB — validation of credentials.
  6. Profile Provision — return of user data.
  7. Mapping in IS — searching for the user based on data from Encvoy ID.
  8. Rights Check — authorization in the target system.
  9. Access Granted — successful login to the system.

📌 Integration Requirements: To connect an information system to Encvoy ID, a user database and an authorization module supporting OpenID Connect or OAuth 2.0 are required.

OpenID Connect Authorization Scheme#

OpenID Connect authorization scheme

Key OIDC Stages:

  1. User accesses the IS.
  2. IS (client) generates code_verifier and code_challenge.
  3. IS redirects the user to /authorize in Encvoy ID.
  4. User is redirected to the Encvoy ID authorization widget.
  5. User enters login/password and provides consent for data transfer.
  6. User check is performed in the Encvoy ID DB.
  7. User is redirected back to the IS (client) with an Authorization code.
  8. IS sends a request to /token in Encvoy ID.
  9. code_challenge and code_verifier validation in Encvoy ID.
  10. Provision of id token containing the Encvoy ID user profile and access token (optionally refresh token) to the IS.
  11. IS user authentication.
  12. User gains access to the IS.

OAuth 2.0 Authorization Scheme#

OAuth 2.0 authorization scheme

OAuth 2.0 Flow Features:

  1. User accesses the IS.
  2. IS redirects the user to /authorize in Encvoy ID.
  3. User is redirected to the Encvoy ID authorization widget.
  4. User enters login/password and provides consent for data transfer.
  5. User check is performed in the Encvoy ID DB.
  6. Encvoy ID redirects the user back to the IS with an Authorization code to the Redirect_URI.
  7. IS sends a request for a token using the Authorization code.
  8. Encvoy ID validates the request.
  9. Encvoy ID returns id token and access token (optionally refresh token).
  10. IS requests the user profile.
  11. Encvoy ID provides the user profile.
  12. IS validates responses and establishes a local user session.
  13. User gains access to the IS.

Single Sign-On (SSO) Scheme#

How Single Sign-On works between multiple systems

Typical Scenario:

  1. Access request to IS1.
  2. User authentication in Encvoy ID.
  3. Provision of Encvoy ID user profile to IS1.
  4. Access request to IS2.
  5. Provision of Encvoy ID user profile to IS2 without repeating the user authentication procedure.
